单电源电压范围： 2.3 V至5.5 V

轨到轨共模输入电压范围

低输入失调电压VOFFSET： 1 mV（典型值）

在0.9 V VCC至欠压闭锁(UVLO)范围内保证比较器输出逻辑低电平

工作温度范围： −40 ℃至+125 ℃

封装类型：

14引脚窄体SOIC封装

14引脚TSSOP

EVAL-ADCMP396 - ADCMP396 Evaluation Board：

Customers of ADCMP391/ADCMP392/ADCMP393/ADCMP394/ADCMP395 comparators may evaluate the performance of these devices using ADCMP396, which has near identical electrical performance to this part and contains a superset of functions featured by this device family.

The EVAL-ADCMP396EBZ features accurate positive and negative voltage monitoring with 0.9% accuracy. The evaluation board uses LEDs to indicate an overvoltage or undervoltage event in both positive and negative voltage being monitored.

The ADCMP396 is a quad rail-to-rail input low power comparator suitable for general-purpose applications. The ADCMP396 consumes only 41.61 μA of supply current making it ideal for battery-powered systems.

The ADCMP396 has a common-mode input range of 200 mV beyond rails, a typical offset voltage of 1 mV across the full common-mode range, and an undervoltage lockout (UVLO) monitor. In addition, the design of the comparator allows a defined output state upon power-up, it generates a logic low output while the supply is still below the UVLO threshold.

The ADCMP396 incorporates a 1 V ± 0.9% buffered reference voltage over line, load, and temperature.
